Rosemounte 3301 Level Transmitter Guided Wave Radar 3301HA1S1V3A 3300 Series

1
MOQ
1300USD~3800USD
τιμή
Rosemounte 3301 Level Transmitter Guided Wave Radar 3301HA1S1V3A 3300 Series
Χαρακτηριστικά Εκθεσιακός χώρος Περιγραφή προϊόντων Ζητήστε ένα απόσπασμα
Χαρακτηριστικά
Προδιαγραφές
Ευαισθησία: Έως 150: 1
Βάρος: Εξαρτάται από το συγκεκριμένο όργανο
Υγρό υλικό: Από ανοξείδωτο χάλυβα? 316 / 316L και CF3M
Ασύρματη τιμή ενημέρωσης: 1 δευτερόλεπτο έως 60 λεπτά, επιλέξιμο από τον χρήστη
Εύρος μέτρησης: Μέχρι 2000 διαφορικό PSI (φραγμός 137,89)
Πρωτόκολλο επικοινωνίας: 4-20 Ma Hart
Κλίμακα θερμοκρασίας: -200°C έως +850°C
Εύρος μέτρησης: Ψηφιακό ή αναλογικό
Βασικές πληροφορίες
Τόπος καταγωγής: ΚΙΝΑ
Μάρκα: Rosement
Αριθμό μοντέλου: Ροζμόουντ 3301
Πληρωμής & Αποστολής Όροι
Συσκευασία λεπτομέρειες: Ξύλινο κουτί/κουτί χαρτιού
Χρόνος παράδοσης: 6-8 εβδομάδες
Όροι πληρωμής: Exw
Δυνατότητα προσφοράς: 300pcs/μήνα
Περιγραφή προϊόντων
Product Details

The Rosemount 3301 Guided Wave Radar Level Transmitter provides reliable and accurate measurement of level and interface in liquids, slurries, and solids. Using guided wave radar (GWR) technology, it is unaffected by changes in process conditions such as temperature, pressure, density, or vapor. Designed for challenging environments, the Rosemount 3301 improves process safety, reduces downtime, and ensures consistent monitoring in critical industrial applications.


Features
  • Guided wave radar technology for continuous level measurement
  • High accuracy independent of temperature, pressure, or vapor changes
  • Robust probe design for long-term durability
  • Suitable for both liquid and solid applications
  • Maintenance-free with no moving parts
  • Easy installation and configuration
  • Compatible with HART communication for remote monitoring

Specifications
  • Measurement Principle: Guided Wave Radar (GWR)
  • Media Compatibility: Liquids, slurries, solids
  • Output Signal: 4–20 mA with HART protocol
  • Measuring Range: Up to 20 m (65 ft) depending on probe
  • Accuracy: ±5 mm
  • Temperature Range: -40 °C to +200 °C (-40 °F to +392 °F)
  • Pressure Range: Vacuum to 40 bar (580 psi)
  • Housing Material: Aluminum or stainless steel
  • Certifications: ATEX, FM, IECEx, SIL-rated

Applications
  • Oil and gas storage tanks
  • Chemical and petrochemical plants
  • Water and wastewater treatment
  • Power generation plants
  • Food and beverage manufacturing
  • Pharmaceutical production facilities

FAQ

Q1: What industries typically use the Rosemount 3301?
A1: It is widely applied in oil & gas, chemicals, water treatment, power generation, and food industries.

Q2: Does it work with solids and slurries?
A2: Yes, the Rosemount 3301 is designed for reliable operation in liquids, slurries, and solids.

Q3: What communication protocols are available?
A3: The transmitter supports 4–20 mA with HART communication.
