Rosemount 3301 HART Guided Wave Radar Level Transmitter ROSEMOUNT 3300 3301 3302 Price

1
MOQ
1300USD~3800USD
τιμή
Rosemount 3301 HART Guided Wave Radar Level Transmitter ROSEMOUNT 3300 3301 3302 Price
Χαρακτηριστικά Εκθεσιακός χώρος Περιγραφή προϊόντων Ζητήστε ένα απόσπασμα
Χαρακτηριστικά
Προδιαγραφές
Ευαισθησία: Έως 150: 1
Βάρος: Εξαρτάται από το συγκεκριμένο όργανο
Υγρό υλικό: Από ανοξείδωτο χάλυβα? 316 / 316L και CF3M
Ασύρματη τιμή ενημέρωσης: 1 δευτερόλεπτο έως 60 λεπτά, επιλέξιμο από τον χρήστη
Εύρος μέτρησης: Μέχρι 2000 διαφορικό PSI (φραγμός 137,89)
Πρωτόκολλο επικοινωνίας: 4-20 Ma Hart
Κλίμακα θερμοκρασίας: -200°C έως +850°C
Εύρος μέτρησης: Ψηφιακό ή αναλογικό
Βασικές πληροφορίες
Τόπος καταγωγής: ΚΙΝΑ
Μάρκα: Rosement
Αριθμό μοντέλου: Ροζμόουντ 3301
Πληρωμής & Αποστολής Όροι
Συσκευασία λεπτομέρειες: Ξύλινο κουτί/κουτί χαρτιού
Χρόνος παράδοσης: 6-8 εβδομάδες
Όροι πληρωμής: Exw
Δυνατότητα προσφοράς: 300pcs/μήνα
Περιγραφή προϊόντων
Product Overview

The Rosemount 3300 Guided Wave Radar Level Transmitter is designed to provide accurate and continuous measurement of level and interface in liquids and bulk solids. Leveraging advanced guided wave radar (GWR) technology, it delivers consistent performance in changing process conditions, including temperature, pressure, vapor, and density variations. With easy installation, no moving parts, and minimal maintenance, the Rosemount 3300 helps industries optimize safety, efficiency, and process reliability.

Features
  • Continuous, non-contact guided wave radar level measurement
  • Reliable performance unaffected by vapor, foam, or turbulence
  • Suitable for both liquid and bulk solid measurement
  • Maintenance-free with robust probe designs
  • Easy to configure with user-friendly interface
  • HART communication for remote monitoring and diagnostics
  • High measurement accuracy for critical process control
Technical Specifications
  • Measurement Technology: Guided Wave Radar (GWR)
  • Measuring Range: Up to 35 m (115 ft) depending on probe type
  • Accuracy: ±5 mm
  • Output Signal: 4–20 mA with HART communication
  • Process Temperature Range: -40 °C to +250 °C (-40 °F to +482 °F)
  • Pressure Range: Vacuum to 40 bar (580 psi)
  • Enclosure Materials: Aluminum or stainless steel
  • Approvals: ATEX, FM, IECEx, SIL certification available
Applications
  • Oil and gas tanks and vessels
  • Petrochemical and chemical processing plants
  • Water and wastewater treatment facilities
  • Food and beverage manufacturing
  • Mining and bulk solids storage
  • Power generation industries
FAQ
Q1: What is the difference between Rosemount 3300 and 3301?
A1: The Rosemount 3300 is an earlier model, offering reliable GWR measurement for liquids and solids, while the 3301 provides enhanced features and higher flexibility in challenging applications.
Q2: Can the Rosemount 3300 measure both liquids and solids?
A2: Yes, it is suitable for continuous level measurement in both liquids and bulk solid applications.
Q3: Is calibration required for installation?
A3: The Rosemount 3300 typically requires minimal or no calibration, simplifying setup and reducing downtime.
